Description
1000 Watts (IEC-705 test procedure).Operating made quick and easy.16 1/8 H x 29 7/8 W x 15 9/16 D
Warranty
| Parts | 1 Year |
|---|---|
| Labor | 1 Year |
WEIGHTS & DIMENSIONS
| Overall Width | 29.875 in |
|---|---|
| Overall Depth | 15.5625 in |
| Overall Height | 16.125 in |
| Approximate Shipping Weight | 63 lb |
| Cabinet Width | 30 in |
| Net Weight | 63 lb |
| Cavity (W x H x D) | 18-13/16 x 9-1/4 x 14-13/32 |
| Cutout Depth (in) | 13 |
| Cutout Height (in) | 16.5 |
| Cutout Width (in) | 30 |
| Depth with Door Open | 39 in |
Other
| Cavity (W x H x D) | 18-13/16 x 9-1/4 x 14-13/32 |
|---|
Dimensions & Weight
| Width | 29.88 in. |
|---|---|
| Height | 16.13 in. |
| Length | 15.56 in. |
| Weight | 63 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
|---|---|
| Shipping Width | 34.88 in. |
| Shipping Height | 21.13 in. |
| Shipping Length | 20.56 in. |
| Shipping Weight | 103 lbs. |
| Total of Shipping Weight | 103 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 4.34 ft³ |
|---|---|
| Dimensional Weight | 53.94 lbs. |
| Total of Cubes | 4.34 ft³ |
| Total of Dimensional Weight | 53.94 lbs. |
FEATURES
| Display Type | LED |
|---|---|
| Electronic Digital Display with Clock | Yes |
| Display Screen Size (Diagonal Length) | 2.01 |
| Cooking Modes | Microwave |
| Express Cook | 1-6 Minutes |
| Control Location | Side Controls |
| Style | Over-The-Range |
| Turntable On / Off | Yes |
| Power Levels | 10 |
| Control Type | Electronic Touch |
| Cooktop Lighting | Bright/Night/Off |
| Product Type | Over-the-range Microwave |
| Turntable | Glass |
| Cooking Technology | Microwave |
| Exhaust Fan | 300-CFM |
| Interior Oven Light | Incandescent |
| Control Features | Cancel/Off |
| Microwave Convenience Cooking Controls | Cook Time |
| Vent | Front |
| Control Features | Vent Fan |
| Microwave Convenience Cooking Controls | Reheat |
| Vent | Top |
| Control Features | Timer On/Off |
| Control Features | Add 30 Seconds |
| Control Features | Turntable On/Off |
| Control Features | Surface Light |
| Control Features | Power Level |
| Control Features | Set Clock |
| Control Features | Start/Pause |
| Control Features | Lock Controls |
| Exhaust Fan | 2-Speed |
| Microwave Convenience Cooking Controls | Popcorn |
| Microwave Convenience Cooking Controls | Beverage |
| Microwave Convenience Cooking Controls | Potato |
| Microwave Convenience Cooking Controls | Defrost: Weight/Time |
| Microwave Watts (IEC-705) | 1,000 W |
| Turntable Size | 12.75 |
| Vent | Back |
APPEARANCE
| Door Swing | Hinges on Left |
|---|---|
| Control Knobs | Brushed Bronze Appearance |
| Handle Color | White |
| Oven Door Features | Oven Window |
| Installation | Easy Mount |
| Door Color | White |
| Case Color | White |
| Color Appearance | White |
ECONOMICAL / QUIET
| Non-Vented | Recirculating (Factory Set - Filter Included) |
|---|---|
| Venting Type | Convertible to External Venting |
ACCESSORIES
| Optional Side Filler Panel Kit | JX36BWW |
|---|---|
| Optional Kits | 15" Bump Out Kit - JX15BUMPWW |
| Recirculating Charcoal Filter Kit | JX81C or WB02X33061 (Included) |
POWER / RATINGS
| Input Volts/Hertz | 120/60 |
|---|---|
| Electrical Input - 120V Amperage | 15 |
| Electrical Input - 120V Watts | 1580 |
WARRANTY
| Labor Warranty | Limited 1-year entire appliance |
|---|---|
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
CAPACITY
| Vent CFM | 300 |
|---|---|
| Total Capacity (cubic feet) | 1.60 cu ft |
- Surface LightPress once for a bright light, twice for a night light
- Popcorn FeatureAchieve perfectly popped popcorn everytime
- Versatile microwave power levels for perfect cookingExperience customized cooking with adjustable power levels, from quick high-heat for veggies and beverages to gentle low-heat for defrosting and delicate sauces
- Express Cook SimplicityJust press a number, 1-6, for equal minutes of cooking time. Enjoy the ease of efficient meal prep, perfect for family dinners or quick snacks
- Charcoal filter replacement for microwaves with behind the door grilleEasily install your new charcoal odor filter
- Convenience cooking controlsOne-touch controls let you quickly cook or reheat popular foods, making everyday meals faster and easier
- Auto and time defrostDefrosting times and power levels are programmed automatically or manually for optimal results
- Turntable On/OffEnjoy versatile cooking with the turntable on/off feature, perfect for evenly heating larger or oddly shaped dishes.
- Two-speed, 300-CFM venting systemRemoves smoke, steam and odors
- Practical Capacity. Dependable Performance.With a 1.6 cu. ft. capacity and 1,000 Watts of power, this microwave provides consistent, even cooking for everyday meals and quick reheats
