Description
Cook up to six grilled cheeses at once on the industry’s largest integrated griddle.Delivers high heat for fast boiling.47 1/4 H x 30 W x 28 3/4 D
Warranty
| Parts | 1 Year |
|---|---|
| Labor | 1 Year |
WEIGHTS & DIMENSIONS
| Overall Width | 30 in |
|---|---|
| Overall Height | 47.25 in |
| Overall Depth | 28.75 in |
| Net Weight | 150 lb |
| Depth Without Handle | 26.25 in |
| Cabinet Width | 30 in |
| Approximate Shipping Weight | 172 lb |
| Depth with Door Open | 46.25 in |
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 19 x 19 |
| Height to Cooking Surface (in.) | 36 - 36.5 |
Other
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 19 x 19 |
|---|
Dimensions & Weight
| Width | 30 in. |
|---|---|
| Height | 47.25 in. |
| Length | 28.75 in. |
| Weight | 150 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
|---|---|
| Shipping Width | 35 in. |
| Shipping Height | 52.25 in. |
| Shipping Length | 33.75 in. |
| Shipping Weight | 190 lbs. |
| Total of Shipping Weight | 190 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 23.58 ft³ |
|---|---|
| Dimensional Weight | 293.19 lbs. |
| Total of Cubes | 23.58 ft³ |
| Total of Dimensional Weight | 293.19 lbs. |
APPEARANCE
| Cooktop Burner Grate Color | Matte Black |
|---|---|
| Handle | Designer Style |
| Oven Door Features | Big View Oven Window |
| Control Knobs | Gloss Black |
| Color Appearance | Black |
FEATURES
| Ignition System | Electronic |
|---|---|
| Burner - Right Rear | 12,000 BTU |
| Oven Rack Features | 2 Flat Nickel Racks |
| Burner - Left Rear | 5,000 BTU Precise Simmer |
| Oven Cleaning Type | Steam Clean |
| Griddle | Integrated (Included) |
| Product Type | Free-Standing Single Oven |
| Cooktop Type | Continuous Grates with Griddle |
| Cooktop Burner Grate Material | Heavy Cast Iron |
| Fuel Type | Natural Gas |
| Burner - Center | 10,000 BTU Oval |
| Interior Oven Light | 1 Incandescent |
| Control Location | Front |
| Cooktop Burner Grate Features | Continuous Grates |
| Control Type | Electronic Touch |
| Burner - Left Front | 15,000 BTU |
| Drawer Type | Broiler |
| Sabbath Mode | Yes |
| Cooking Technology | Traditional |
| Configuration | Range with Broiler Drawer |
| OU Certified | Embedded OU/CRC Enhanced Shabbos Mode |
| Cooktop Burner Type | Sealed |
| Burner - Right Front | 9,500 BTU |
| Oven Rack Positions (Single or Upper/Lower) | 6 |
| Cooktop Surface | Edge-to-Edge |
| Oven Control Features | Auto Oven Shut-Off |
| Oven Control Features | Oven Control Lock Capability |
| Cooktop Surface | Porcelain-Enamel |
| Cooktop Surface | One-Piece Upswept |
| Cooktop Surface | Black |
| Oven Control Features | Audible Preheat Signal |
| Oven Control Features | Delay Bake Option |
| Oven Control Features | Electronic Clock and Timer |
| Oven Control Features | Hi / Low Broil |
POWER / RATINGS
| Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 10.0 |
|---|---|
| Volts/Hertz/Amps | 120v; 60Hz; 15A |
| Top Burner BTU Rating - LP (000's BTU's) | (1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 8.0 |
| Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) | 18.0 Bake / 18.0 Broiler |
| Bake/Broiler BTU Rating - LP (000's BTU's) | 16.0 Bake / 16.0 Broiler |
ACCESSORIES
| Center Grate | Optional - JXGRATE1 |
|---|---|
| Griddle Accessory | Integrated Griddle (Included) |
| LP Conversion Kit | Included |
WARRANTY
| Parts Warranty | Limited 1-year entire appliance |
|---|---|
| Labor Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
CAPACITY
| Total Capacity (cubic feet) | 5.00 cu ft |
|---|
- Edge-to-edge cooktopA large cooking surface gives you extra room for pots and pans of all sizes and lets cookware move easily from burner to burner
- Extra-large integrated griddleCook up to six grilled cheeses at once on the industry’s largest integrated griddle
- 15,000 BTU Power Boil BurnerDelivers high heat for fast boiling
- Center oval burnerLarge oval fifth burner is ideal for griddle cooking
- Steam cleanSave time and effort by steam-cleaning the oven after cooking. No special water, kits or extra steps required.
- Precise Simmer burnerDelicate foods don’t burn with low, even heat
- Heavy duty, dishwasher-safe gratesEasily and safely clean grates in the dishwasher
- 5.0 cu. ft. oven capacityCook more dishes at once
- Sealed cooktop burnersContains spills and make cleaning quick and easy
- Deep-recessed cooktopContains spills for quick and easy cleaning
- Flexible broilingBroil in any size cookware with a flexible broiling element that can be set to hi or low based on your broiling needs
- Electronic clock and timerHelp cooks coordinate meal preparation and cooking
