Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
35 in.
Shipping Height
40 in.
Shipping Length
31 in.
Shipping Weight
218 lbs.
Total of Shipping Weight
218 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
15.8 ft³
Dimensional Weight
196.4 lbs.
Total of Cubes
15.8 ft³
Total of Dimensional Weight
196.4 lbs.
Product Details
Sabbath Mode
Yes
Height
35 3/8"
Width
30"
Depth
28 1/2"
Depth
26"
Depth With Door 90° Open
47 5/16"
Control Lock
Yes
Air Fry
Yes
Bake
Yes
Broil
Yes
Clock
Yes
Convection Bake
Yes
Convection Roast
Yes
Cooktop Lockout
Yes
Delay Clean
Yes
Delay Start
Yes
Door Lock
Yes
Hot Surface
Yes
Kitchen Timer
Yes
Light
Yes
Lockout
Yes
No Preheat
Yes
Oven Light
Yes
Preheat
Yes
Probe
Yes
Self Clean
Yes
Set Clock
Yes
Slow Cook
Yes
Steam Bake
Yes
Steam Clean
Yes
Steam Roast
Yes
Temperature Display
Yes
Timer On / Off
Yes
User Preferences
Yes
Delayed Bake
Yes
Program Fahrenheit or Celsius
Yes
Silent Control Panel
Yes
ADA Compliant
Yes
RoHS
Yes
Star-K Certification
Yes
UL Listed
Yes
Auto Pan Detect
Yes
Bridge Element Location
Left
Cooking Surface Type
Smooth
Element On Indicator Light
Yes
Hot-Surface Indicator Light
Yes
Right Front Element Burner Size
8 3/10"
Right Rear Element Burner Size
5 1/2"
Left Front Element Burner Size
7"
Left Rear Element Burner Size
7"
Center Rear Element Burner Size
5 1/2"
Right Front Element Burner
2,300 / 3,600 Watts (Boost)
Right Rear Element Burner
1,400 / 2,500 Watts (Boost)
Left Front Element Burner
1,800 / 2,800 Watts (Boost)
Left Rear Element Burner
1,800 / 2,800 Watts (Boost)
Center Element Burner
1,400 / 2,500 Watts (Boost)
Minimum Height
35 3/8"
Maximum Height
36 3/8"
Standard Width
30"
Depth With Handle
28 1/2"
Oven Interior Height
21 5/16"
Oven Interior Width
25 3/16"
Oven Interior Depth
19 7/8"
Oven Capacity
6.2 Cu. Ft.
Drawer Type
Storage
Connected Load @ 240V
15 kW
Minimum Circuit Required
40 Amps
Voltage Rating
240 V
Adjustable Leveling Legs
Yes
Backlit Knobs
Yes
Exterior Finish
Smudge-Proof® Stainless Steel
Product Weight
178 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
AB-1200
Information available at frigidaire.com/en/ab1200
Bake Element
2500 Watts
Bake Element Pass
8
Bake Element Type
Hidden
Broil Element
4000 Watts
Broil Element Pass
6
Cleaning System
Yes
Convection
Yes
Convection Element
3800 Watts
Convection Type
Total
Number of Convection Fans
1
Number of Rack Positions
7
Oven Interior Color
Midnight Black
Oven Light Quantity
2
Oven Light Type
Halogen
Oven Light Watts
40 Watts
Rack Position Type
Embossed
Rack Type 1
Handle Bull Nose
Rack Type 1 Quantity
1
Rack Type 2
Glide
Rack Type 2 Quantity
1
Rack Type 3
Air Fry Tray
Rack Type 3 Quantity
1
Display Interface Color
White
Display Type
Capacitive Touch
Total Convection SystemGives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast and more!
Easy-to-Clean CooktopUnlike traditional electric and gas cooktops, Induction only heats the pan and the food in it, so the area around the pan stays cooler, allowing you to clean up spills and splatters while you cook.
No PreheatEliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.
ReadyCook™ Air Fry Tray is includedFor perfectly crispy and delicious Air Fry results.
Faster Boil TimesWith induction, heat transfers directly to the cookware bypassing the cooktop surface, making induction incredibly fast.
Temperature ProbeMonitors and alerts when the desired finished cooking temperature has been reached.
Steam BakeWith Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
Consistent temperature with TempLock™Sensors in the cooktop automatically adjust the power level to maintain a consistent temperature the entire time you cook - it's like cruise control for your cooktop
Convenient Bridge ElementConnects two elements to allow for simultaneous control, perfect for a griddle pan.
Two cleaning optionsSelect Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
Backlit LED KnobsLights up when the cooktop is turned on.
Premium Glide RackOur extending Glide Rack makes it easier to monitor and lift your food out of the oven.
Safer Cooktop SurfaceInduction only heats the pan and the food in it, so the area around the pan stays cooler.
Extra Wide Store-More™ Storage DrawerRedesigned to be even wider - allowing you to store any unused oven racks, baking trays and more!
Smudge-Proof® Stainless SteelResists fingerprints and cleans easily.
Frigidaire® Fit PromiseWe promise that your new 30" Frigidaire front control range will fit your existing range cutout of the same width and configuration, or we will reimburse you up to one hundred dollars for professionally modifying the countertop.
Proudly Assembled in the USA
Air FryMake healthier and delicious meals for your entire family - right in your oven.
Slow CookWith Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
