Warranty
| Parts | 1 Year |
|---|---|
| Labor | 1 Year |
| Labor Warranty | Limited 1-year entire appliance |
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
Dimensions & Weight
| Width | 30 in. |
|---|---|
| Height | 46.75 in. |
| Length | 28.75 in. |
| Weight | 135 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
|---|---|
| Shipping Width | 35 in. |
| Shipping Height | 51.75 in. |
| Shipping Length | 33.75 in. |
| Shipping Weight | 175 lbs. |
| Total of Shipping Weight | 175 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 23.33 ft³ |
|---|---|
| Dimensional Weight | 290.09 lbs. |
| Total of Cubes | 23.33 ft³ |
| Total of Dimensional Weight | 290.09 lbs. |
Features
| Control Type | Rotary knobs |
|---|---|
| Product Type | Free-Standing Single Oven |
| Sabbath Mode | Yes |
| Configuration | Range with Storage Drawer |
| Control Location | Backsplash |
| Fuel Type | Electric |
| Cooktop Burner Type | Coil |
| Cooking Technology | Traditional |
| Cooktop Surface | One-Piece Upswept, Porcelain-Enamel |
| Element - Left Front | 6" 1250W Temp Limiting Coil |
| Element - Left Rear | 6" 1250W Temp Limiting Coil |
| Element - Right Front | 8" 2400W Temp Limiting Coil |
| Element - Right Rear | 6" 1250W Temp Limiting Coil |
| Lift-up Cooktop With Support Rods | Yes |
| Oven Control Features | Oven "ON" Light |
| Oven Features | 4-Pass Bake Element, 4-Pass Broil Element |
| Oven Cleaning Type | Standard Clean |
| Oven Rack Features | 2 Oven Racks |
| Removable One-piece Drip Bowls | Chrome |
| Storage Drawer Features | Removable Full-Width |
| Drawer Type | Lower Storage Drawer |
| Cooktop Type | Coil |
| Infinite Heat Controls | Yes |
| Heating Element "on" Indicator Light | Yes |
| Ou Certified | No |
| Oven Rack Positions (single Or Upper/lower) | 6 |
Capacity
| Total Capacity (cubic Feet) | 5 cu ft |
|---|
Appearance
| Color Appearance | White |
|---|---|
| Handle Color | White |
| Control Knobs | White |
Weights & Dimensions
| Overall Depth | 28 3/4 in |
|---|---|
| Overall Height | 46 3/4 in |
| Overall Width | 30 in |
| Approximate Shipping Weight | 155 lb |
| Cabinet Width | 30 in |
| Depth With Door Open | 46 3/4 in |
| Oven Interior Dimensions (w X H X D) (in.) | 23-3/4 x 19 x 18-1/2 |
| Net Weight | 150 lb |
| Height To Cooking Surface (in.) | 36 - 36.5 |
Power / Ratings
| Electrical Requirements | 208/240V ; 60Hz ; 40A |
|---|---|
| Kw Rating At 208v | 8.0 |
| Kw Rating At 240v | 10.1 |
| Amp Rating At 208v | 40 |
| Amp Rating At 240v | 40 |
| Bake Wattage | 2585W |
| Broiler Wattage | 3410W |
| Hertz | 60 |
Claims & Certifications
| 60 | Yes |
|---|
