Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
32 in.
Shipping Height
34 in.
Shipping Length
29 in.
Shipping Weight
150 lbs.
Total of Shipping Weight
150 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
10.88 ft³
Dimensional Weight
135.19 lbs.
Total of Cubes
10.88 ft³
Total of Dimensional Weight
135.19 lbs.
Product Details
Sabbath Mode
Yes
Height
29 1/2"
Width
27"
Depth
27 7/16"
Depth
24 3/4"
Depth With Door 90° Open
45 3/4"
Minimum Cutout Height
27 1/4"
Minimum Cutout Width
24 7/8"
Maximum Cutout Height
28 1/4"
Maximum Cutout Width
25 1/4"
Control Lock
Yes
Air Fry
Yes
Air Sous Vide
Yes
Bake
Yes
Bake Time
Yes
Broil
Yes
Cancel
Yes
Clock
Yes
Convection Bake
Yes
Convection Roast
Yes
Delay Start
Yes
Fast Preheat
Yes
Kitchen Timer
Yes
Light
Yes
My Favorite
Yes
No Preheat
Yes
Off
Yes
Oven Light
Yes
Preheat
Yes
Probe
Yes
Quick Preheat
Yes
Self Clean
Yes
Set Clock
Yes
Start
Yes
Start Time
Yes
Steam Bake
Yes
Steam Clean
Yes
Steam Roast
Yes
Stop
Yes
Temperature Display
Yes
Timer On / Off
Yes
User Preferences
Yes
Warm and Hold
Yes
Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
Yes
Program Fahrenheit or Celsius
Yes
Silent Control Panel
Yes
ADA Compliant
Yes
RoHS
Yes
Star-K Certification
Yes
UL Listed
Yes
Standard Width
27"
Depth With Handle
27 7/16"
Oven Interior Height
17"
Oven Interior Width
20 1/2"
Oven Interior Depth
18 3/4"
Oven Capacity
3.8 Cu. Ft.
Amps @ 240 Volts
20 Amps
Connected Load @ 240V
4.5 kW
Minimum Circuit Required
20 Amps
Voltage Rating
240 V
Handle Color
Stainless Steel
Frigidaire Fit Promise
Yes
Product Weight
110 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
AB-1200
Information available at frigidaire.com/en/ab1200
Power Supply Connection Location
Top Right
Bake Element
2500 Watts
Bake Element Pass
8
Bake Element Type
Hidden
Broil Element
4000 Watts
Broil Element Pass
6
Broil System
Yes
Cleaning System
Yes
Convection
Yes
Convection Element
2500 Watts
Convection Type
Total
Number of Convection Fans
1
Number of Rack Positions
5
Oven Interior Color
Midnight Black
Oven Light Quantity
2
Oven Light Type
Halogen
Oven Light Watts
40 Watts
Rack Position Type
Embossed
Rack Type 1
Handle
Rack Type 2
Glide
Rack Type 2 Quantity
1
Display Interface Color
White
Display Light Color
White
Display Type
Capacitive Touch
Included Steam Tray
Yes
Exterior Finish
Smudge-Proof® Stainless Steel
Rack Type 1 Quantity
1
Air FryMake healthier and delicious meals for your entire family - right in your oven.
Slow CookWith Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
Total Convection SystemGives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Air Sous Vide, Bread Proof, Dehydrate and more!
No PreheatEliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.
Temperature ProbeMonitors and alerts when the desired finished cooking temperature has been reached.
Steam BakeWith Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
Frigidaire® Fit PromiseWe promise that your new 27" Frigidaire® Gallery single wall oven will fit your existing cabinet cutout of the same width and configuration, or we will reimburse you up to $300 for cabinet modification costs.
Self and Steam Clean CyclesEnjoy more cleaning flexibility. Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
Steam RoastSteam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.
Premium Touch Screen Control PanelFeatures a responsive 4.3 inch, full color, capacitive touch digital control panel.
Air Sous VideUses precisely-controlled temperature and airflow to lock in flavor and moisture to cook foods to the finish temperature you want.
ReadyCook™ Air Fry Tray-Sold separatelyOptional ReadyCook™ Air Fry Tray allows you to achieve perfectly crispy and delicious results.
Smudge-Proof® Stainless SteelResists fingerprints and cleans easily.
