Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
35 in.
Shipping Height
7 in.
Shipping Length
26 in.
Shipping Weight
74 lbs.
Total of Shipping Weight
74 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
0.73 ft³
Dimensional Weight
7.59 lbs.
Total of Cubes
0.73 ft³
Total of Dimensional Weight
7.59 lbs.
Product Details
Height
2 5/8"
Width
30 5/8"
Depth
21 3/8"
Minimum Cutout Width
28 1/2"
Minimum Cutout Depth
19 5/8"
Maximum Cutout Width
29 7/8"
Maximum Cutout Depth
20 1/2"
ADA Compliant
Yes
CSA Listed
Yes
UL Listed
Yes
Bridge Element
Yes
Bridge Element Location
Left
Cooking Surface Type
Smooth
Hot-Surface Indicator Light
Yes
Right Front Element Burner Size
9"
Left Front Element Burner Size
7"
Left Rear Element Burner Size
7"
Center Front Element Burner Size
6"
Right Front Element Burner
3200 Watts
Left Front Element Burner
1800 Watts
Left Rear Element Burner
1800 Watts
Center Front Element Burner
1200 Watts
Center Rear Element Burner
100 Watts
Keep Warm Burner Location
Center Rear
Standard Width
30"
Cutout Height
5"
Connected Load @ 240V
8.1 kW
Minimum Circuit Required
40 Amps
Voltage Rating
240 V
Frigidaire Fit Promise
Yes
Product Weight
34 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
Installed Over a Wall Oven
Yes
Display Type
Mechanical
EvenTemp® ElementHeat is evenly distributed across the element's surface, which reduces hot spots and cold areas in your pan.
Bridge ElementConnect two elements to create a larger cooking surface, perfect for griddles or large pans.
Frigidaire® Fit PromiseWe promise that your new 30" Frigidaire Professional radiant cooktop will fit your existing countertop cutout of the same width and configuration, or we will reimburse you for cabinet modification costs up to $100(1)
Keep Warm ZoneKeeps dishes warm while the rest finish so that your entire meal is ready when you are.
Backlit LED KnobsLights up when an element is on, so you know when your cooktop is in use.
Front Control DesignAdjust the cooking temperature without having to reach over hot items on the cooktop
Installation over Wall Oven ApprovedCooktops are approved for installation above any of our Frigidaire electric wall ovens.
Smudge-Proof® Stainless SteelResists fingerprints and cleans easily.
Easy-to-Clean Glass CooktopWipe away spills more easily with the smooth ceramic glass cooktop
