Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
34 in.
Shipping Height
46 in.
Shipping Length
30 in.
Shipping Weight
325 lbs.
Total of Shipping Weight
325 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
17.2 ft³
Dimensional Weight
213.85 lbs.
Total of Cubes
17.2 ft³
Total of Dimensional Weight
213.85 lbs.
Product Details
Sabbath Mode
Yes
Height
41 9/16"
Width
30"
Depth
27 3/5"
Width
29 7/8"
Depth
25 3/16"
Depth With Door 90° Open
48 3/16"
Minimum Cutout Height
40 5/8"
Minimum Cutout Width
28 1/2"
Maximum Cutout Height
41 1/2"
Maximum Cutout Width
29"
Control Lock
Yes
Air Fry
Yes
Air Sous Vide
Yes
Bake
Yes
Bake Time
Yes
Broil
Yes
Cancel
Yes
Child Lock
Yes
Clear Off
Yes
Clock
Yes
Convection Bake
Yes
Convection Roast
Yes
Cook Time
Yes
Dehydrate
Yes
Delay Clean
Yes
Delay Start
Yes
Fast Preheat
Yes
Keep Warm
Yes
Kitchen Timer
Yes
Light
Yes
My Favorite
Yes
No Preheat
Yes
Off
Yes
Oven Light
Yes
Preheat
Yes
Probe
Yes
Self Clean
Yes
Set Clock
Yes
Slow Cook
Yes
Start
Yes
Start Time
Yes
Steam Bake
Yes
Steam Clean
Yes
Steam Roast
Yes
Stop
Yes
Temperature Display
Yes
Timed Bake
Yes
Timer On / Off
Yes
User Preferences
Yes
Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
Yes
Delayed Bake
Yes
Program Fahrenheit or Celsius
Yes
Silent Control Panel
Yes
Timed Cooking
Yes
CSA Listed
Yes
RoHS
Yes
Star-K Certification
Yes
UL Listed
Yes
Standard Width
30"
Depth With Handle
27 3/5"
Cutout Depth
23 5/8"
Oven Interior Height
18 1/8"
Oven Interior Width
25 3/16"
Oven Interior Depth
19 7/8"
Microwave Interior Height
9 5/16"
Microwave Interior Width
18 7/8"
Microwave Interior Depth
16 1/8"
Microwave Capacity
1.7 Cu. Ft.
Oven Capacity
5.3 Cu. Ft.
Amps @ 240 Volts
40 Amps
Connected Load @ 240V
7.6 kW
Minimum Circuit Required
40 Amps
Voltage Rating
240 V
Door Swing
Drop-Down Door
Exterior Finish
Smudge-Proof® Stainless Steel
Frigidaire Fit Promise
Yes
Product Weight
285 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
AB-1200
Information available at frigidaire.com/en/ab1200
Power Supply Connection Location
Top Left
Rack
Yes
Turntable Diameter
14"
Turntable Material
Glass
Microwave Cooking Power
1000 Watts
Bacon
Yes
Beverage
Yes
Defrost
Yes
Melt / Soften
Yes
Popcorn
Yes
Reheat
Yes
Rice
Yes
Top Grill Mode
Yes
Veggies
Yes
Bake Element
2600 Watts
Bake Element Pass
4
Bake Element Type
Hidden
Broil Element
4000 Watts
Broil Element Pass
6
Broil System
Yes
Cleaning System
Yes
Convection
Yes
Convection Element
3800 Watts
Convection Type
Total
Number of Convection Fans
1
Number of Rack Positions
6
Oven Interior Color
Midnight Black
Oven Light Quantity
2
Oven Light Type
Halogen
Oven Light Watts
40 Watts
Rack Position Type
Embossed
Rack Type 1
Handle
Rack Type 1 Quantity
2
Rack Type 2
Glide
Rack Type 2 Quantity
1
+ 30 Seconds
Yes - One Touch
Display Interface Color
White
Display Light Color
White
Display Type
Capacitive Touch
Convection Cooking - Bake
Yes
Convection Element
1650 Watts
Total Convection SystemGives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast and more!
No PreheatEliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.
ReadyCook™ Air Fry Tray is includedFor perfectly crispy and delicious Air Fry results.
Steam BakeWith Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
Temperature ProbeMonitors and alerts when the desired finished cooking temperature has been reached.
Frigidaire® Fit PromiseWe promise that your new 30" Frigidaire® Professional Microwave Combination Oven will fit your existing cabinet cutout of the same width and configuration, or we will reimburse you up to $300 for cabinet modification costs.
Convection CookingGet the great tasting results of the conventional convection oven, combined with the speed of microwave technology with our convection bake.
Self and Steam Clean CyclesEnjoy more cleaning flexibility. Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
Premium Touch Screen Control PanelFeatures a responsive 4.3 inch, full color, capacitive touch digital control panel.
Extra Large Oven CapacityCook more at once with our extra large, 5.3 cu.ft. capacity oven.
Premium Glide RackOur extending Glide Rack makes it easier to monitor and lift your food out of the oven.
Smudge-Proof® Stainless SteelResists fingerprints and cleans easily.
Air FryMake healthier and delicious meals for your entire family - right in your oven.
Slow CookWith Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
