Description
Easily adjust to any size pot or pan with a convertible 6″ and 9″ element that makes it easy to boil water faster..Wipe away messes with ease on this easy-to-clean cooktop with smooth glass surface..47 1/4 H x 30 W x 27 7/8 D
Warranty
| Parts | 1 Year |
|---|---|
| Labor | 1 Year |
FEATURES
| Configuration | Range with Storage Drawer |
|---|---|
| Oven Features | 4-Pass Broil Element |
| Element - Right Front | 9"/6" 3100W Power Boil |
| Cooking System | Traditional |
| Interior Oven Light | 1 Light |
| Fuel Type | Electric |
| Oven Interior | Black Enamel |
| OU Certified | OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately |
| Oven Control Features | Oven "ON" Light |
| Oven Cooking Modes | Low Broil |
| Cooktop Burner Type | Smoothtop |
| Oven Rack Features | 2 Nickel Racks |
| Power Boil Burner | Yes |
| Element - Left Front | 8" 2000W |
| Oven Cleaning Type | Steam Clean |
| Hot Surface Indicator Lights | Yes |
| Product Type | Free-Standing Single Oven |
| Heating Element "ON" Indicator Light | Yes |
| Cooktop Type | Radiant Smoothtop |
| Element - Left Rear | 6" 1200W |
| Sabbath Mode | Yes |
| Dual Ring Burners | Yes |
| Element - Right Rear | 6" 1200W |
| Cooktop Surface | Porcelain-Enamel Perimeter |
| Control Location | Backsplash |
| Drawer Type | Storage |
| Oven Rack Positions (Single or Upper/Lower) | 6 |
| Control Type | Touchpads |
| Cooking Technology | Traditional |
| Control Type | Digital Temperature Display |
| Control Type | Electronic |
| Cooktop Burner Type | Radiant |
| Cooktop Surface | One-Piece Upswept |
| Cooktop Surface | Black Ceramic Glass |
| Oven Control Features | Electronic Clock & Kitchen Timer |
| Oven Control Features | Hi / Low Broil |
| Oven Control Features | Cook Time |
| Oven Cooking Modes | Bake |
| Oven Cooking Modes | High Broil |
| Oven Features | 4-Pass Bake Element |
WEIGHTS & DIMENSIONS
| Net Weight | 147 lb |
|---|---|
| Depth Without Handle | 25.5 in |
| Oven Interior Dimensions (W x H x D) (in.) | 24-1/8 x 19-1/2 x 19-3/8 |
| Depth with Door Open | 47.5 in |
| Cabinet Width | 30 in |
| Approximate Shipping Weight | 159 lb |
| Overall Width | 30 in |
| Overall Depth | 27.875 in |
| Overall Height | 47.25 in |
| Height to Cooking Surface (in.) | 35.625 - 36.5 |
POWER / RATINGS
| KW Rating at 240V | 11.0 |
|---|---|
| Bake Wattage | 2585W |
| Electrical Requirements | 240V,5600W,24A,60Hz or 208V,4400W,22A,60Hz |
| Amp Rating at 208V | 40 |
| Broiler Wattage | 3410W |
| KW Rating at 208V | 8.3 |
| Amp Rating at 240V | 40 |
| Hertz | 60 |
| Watts | 5600/4400 |
APPEARANCE
| Oven Door Features | Glass Door |
|---|---|
| Control Knobs | White |
| Handle Color | White |
| Color Appearance | White |
| Oven Door Features | Big View Oven Window |
ACCESSORIES
| Extension Rack | Optional - JXXTNRCK2 |
|---|
WARRANTY
| Labor Warranty | Limited 1-year entire appliance |
|---|---|
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
Dimensions & Weight
| Width | 30 in. |
|---|---|
| Height | 47.25 in. |
| Length | 27.88 in. |
| Weight | 147 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
|---|---|
| Shipping Width | 35 in. |
| Shipping Height | 52.25 in. |
| Shipping Length | 32.88 in. |
| Shipping Weight | 187 lbs. |
| Total of Shipping Weight | 187 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 22.87 ft³ |
|---|---|
| Dimensional Weight | 284.26 lbs. |
| Total of Cubes | 22.87 ft³ |
| Total of Dimensional Weight | 284.26 lbs. |
CAPACITY
| Total Capacity (cubic feet) | 5.30 cu ft |
|---|
- 4 Burner Radiant CooktopThis expansive 4 burner electric cooktop offers a flexible cooking solution that accommodates any pot or pan and is a great addition to any kitchen space.
- Ceramic Glass CooktopWipe away messes with ease on this easy-to-clean cooktop with smooth glass surface.
- Steam CleanSave your time and effort by steam-cleaning the oven after use without the need for special water, kits, or extra steps thanks to this simple steam clean oven function.
- Oven Storage DrawerThis model features a removable oven storage drawer that offers the perfect place to store cookware and other kitchen accessories.
- Dual Element OvenProduce great results with every bake thanks to upper and lower elements that provide rapid, even heat.
- Large Capacity OvenCook an entire meal at once with room to spare in this oven with 5.3 cubic foot capacity.
- New Easy-to-Use ControlsUpdated and improved controls allow for easy navigation of all cooking options and modes.
- Nickel RacksThis electric range with nickel racks provides a durable design that handles heavy baking dishes with ease.
- 4-Pass Bake ElementEnjoy perfect results on all your baked foods thanks to even heat distribution in this 4-pass bake element oven.
- Halogen Oven LightEasily view your delicious dinner creations inside this oven illuminated with powerful halogen oven light.
- Sabbath ModeThis oven with Sabbath Mode gives users the ability to modify or disable certain features and comply with religious restrictions.
- 9"/6" Power Boil burnerEasily adjust to any size pot or pan with a convertible 6" and 9" element that makes it easy to boil water faster.
- 9"/6" Power Boil BurnerEasily adjust to any size pot or pan with a convertible 6" and 9" element that makes it easy to boil water faster.
