Automatic Convection Conversion Temperature Adjust
No
Broiler Location
Top Center
Convection Element Type
None
Convection Functions
No
Door Removable
Yes
Hidden Bake Element
Yes
Interior Color
Grey
Number of Oven Lights
1
Oven Cleaning Type
Steam Clean
Number of Oven Racks
2
Number of Rack Guides
5
Oven Light Type
Halogen
Oven Cooking System
Thermal
Oven Light Switch Location
Oven Control
Oven Rack Type
Standard (Both)
Temperature Probe
No
Temperature Sensor
No
Bake Element Power
2,400 W
Broiler Element Power
3,400 W
Cooktop Details
Cooktop Control Knob Color
Stainless Steel
Auto Re-ignition
No
Cooktop Control Knob Type
Plastic
Cooktop Control Location
Backguard
Cooktop Control Type
Knobs
Cooktop Surface Material
Glass
Cooktop Surface Color
Black
Heating Element On Indicator Light
Yes
Hot Surface Indicator Light
Yes
Details
Cooktop Configuration
All Burners
Fuel Type
Electric
Natural Gas Convertible
No
Oven Selections
Audible Signal, Bake, Broil, Cancel/Off, Clock, Control Lock, Cook Time Indicator, Delay Start, Keep Warm/Warm Hold, Sabbath Mode, Start Time, Stop Time, Timer
Oven Automatic Shut-Off
Yes
Power On Indicator Light
Yes
Power Outage Compatible
No
Range Configuration
Freestanding
Range Type
Freestanding
Temperature Probe
No
Element/Burner Details
Center Front Element-Burner Power
100W
Center Front Element-Burner Type
Warming
Center Front Element-Burner Size
6in.
Center Rear Element-Burner Power
100W
Center Rear Element-Burner Size
6in.
Center Rear Element-Burner Type
Warming
Cooktop Element Style
Radiant
Left Front Element-Burner Power
3000W/1400W
Left Front Element-Burner Type
Dual
Left Front Element-Burner Size
9in./6in.
Left Rear Element-Burner Size
6in.
Left Rear Element-Burner Type
Single
Number of Cooking Element-Burners
5
Right Front Element-Burner Power
1950W/3000W
Right Front Element-Burner Size
12in./9in.
Right Front Element-Burner Type
Dual
Right Rear Element-Burner Size
6in.
Right Rear Element-Burner Type
Single
Left Rear Element-Burner Power
1,200W
Right Rear Element-Burner Power
1,200W
Smart Compatibility
Works With
No
Connectivity
No
Controls
Display Color
Blue
Electronic Display Type
LED
Electrical
Power Cord Included
No
Amps
40
Hz
60
Volts
208
Watts
7
Dimensions & Weight
Width
29.88 in.
Height
47.88 in.
Length
27.75 in.
Weight
185 lbs.
Cutout Height
36 in
Cutout Depth
24 in
Cutout Width
30 in
Depth Closed Excluding Handles
25-313/1000 in
Depth Closed Including Handles
27-3/4 in
Gross Weight
185 lbs
Depth With Door Open 90 Degree
46-86/125 in
Net Weight
169 lbs
Oven Interior Depth
19-5/8 in
Oven Interior Height
19-1/8 in
Oven Interior Width
24-1/4 in
Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
34.88 in.
Shipping Height
52.88 in.
Shipping Length
32.75 in.
Shipping Weight
225 lbs.
Total of Shipping Weight
225 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
22.97 ft³
Dimensional Weight
285.54 lbs.
Total of Cubes
22.97 ft³
Total of Dimensional Weight
285.54 lbs.
Certifications
ADA Compliant
No
CUL
Yes
Energy Star Qualified
Yes
Star K Certified
Kosher Consumer Friendly
UL
Yes
Energy Star® Qualified
Yes
Prop 65
Standard
Steam CleanTackle oven mess in an hour or less with Steam Clean self-cleaning technology. To lift light soils in less than an hour, simply add water, run the cycle and wipe with a wet sponge when the cycle is finished.
Warming centerA Warming Center adds a dedicated cooktop zone to keep your finished food warm while you use the other elements to get the rest of your meal cooked.
Edge-to-Edge Ceramic Glass CooktopThe easy-to-clean, Edge-to-Edge Ceramic Glass Cooktop lets you easily wipe spills and splatters.
Variable BroilVariable Broil delivers the temperatures you need for fast cooking. Set the oven between 350°F and 500°F to get the results you want on meat, sweet peppers and more.
10 year limited parts warranty*With a 10-year limited parts warranty* on the glass cooktop, elements and cavity, we built these ranges tough enough to keep cooking for years.*See product warranty for details.
Delay BakeWith the Delay Bake setting, you can place your dishes inside the oven and schedule when you want the baking to begin so your food is ready when you are.
Large Capacity 5.3 cu ftCook the whole meal with plenty of space in this 5.3 cu. ft. large capacity electric range.
Proudly assembled in Tulsa, Oklahoma, U.S.A.We take pride in building strong, reliable appliances for your home. These ranges are proudly assembled by hard-working employees in Tulsa, Oklahoma.
An American company for over 100 yearsWhirlpool Corporation started in 1911 in Benton Harbor, Michigan. Today we are a global home appliance business selling products around the world. We are proud of our American heritage and ingenuity that have driven innovation for over 100 years.
Better Built Electric RangeSturdy door hinges on this Maytag® electric range are built for dependability, while the fingerprint resistant stainless finish and ceramic glass cooktop help make cleaning easy.
Spacious Storage DrawerStore your most-used cookware in our spacious oven drawer. Fit up to 5 pots and pans including skillets, sauce pans, stockpot and more.
Sabbath ModeSabbath mode keeps the oven in Bake mode until it can be shut off, allowing you to cook and warm food during the Sabbath. All other oven settings, including temperature displays, sounds, changes in light status and cleaning cycles will be disabled.
ENERGY STAR® CertifiedENERGY STAR® Certified models exceed government standards to help save money on your utility bills.
Keep Warm™No need to reheat dinner. The Keep Warm™ setting uses low heat to keep food warm and ready to eat.
Precision Cooking™ SystemThe Precision Cooking™ System uses sensor heating to monitor cavity temperatures to help ensure each meal is cooked evenly.
9"/6" Dual-Choice™ elementThe 9"/6" Dual-Choice™ Element matches the heat to the pan you’re using so you can cook your meal the way you want.
