Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
40 in.
Shipping Height
40 in.
Shipping Length
30 in.
Shipping Weight
280 lbs.
Total of Shipping Weight
280 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
17.72 ft³
Dimensional Weight
220.32 lbs.
Total of Cubes
17.72 ft³
Total of Dimensional Weight
220.32 lbs.
Product Details
Sabbath Mode
Yes
Height
35 3/4"
Width
35 7/8"
Depth
27 5/8"
Depth
25 7/8"
Depth With Door 90° Open
43 3/8"
Control Lock
Yes
Air Fry
Yes
Bake
Yes
Bread Proof
Yes
Broil
Yes
Clock
Yes
Convection Bake
Yes
Convection Convert
Yes
Convection Roast
Yes
Cook Time
Yes
Dehydrate
Yes
Delay Clean
Yes
Delay Start
Yes
Door Lock
Yes
Keep Warm
Yes
Kitchen Timer
Yes
Lockout
Yes
On-Off
Yes
Oven Light
Yes
Oven Lock
Yes
Probe
Yes
Quick Preheat
Yes
Self Clean
Yes
Set Clock
Yes
Slow Cook
Yes
Steam Bake
Yes
Steam Clean
Yes
Steam Roast
Yes
Temperature Display
Yes
Timer On / Off
Yes
Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
Yes
Delayed Bake
Yes
Program Fahrenheit or Celsius
Yes
Silent Control Panel
Yes
CSA Listed
Yes
RoHS
Yes
Star-K Certification
Yes
Cooking Surface Type
Gas
Grate Material
Cast Iron
Grate Quantity
3
Grate Style
Continuous
Sealed Burners
Yes
Total Number of Burners
6
Right Front Element Burner
18,000 / 1,200 BTU Dual
Right Rear Element Burner
5,000 / 500 BTU
Left Front Element Burner
18,000 / 1,200 BTU Dual
Left Rear Element Burner
9,000 / 850 BTU
Center Front Element Burner
16,000 / 2,000 BTU
Center Rear Element Burner
16,000 / 2,000 BTU
Minimum Height
35 3/4"
Maximum Height
36 1/2"
Standard Width
36"
Depth With Handle
27 5/8"
Oven Interior Height
13 3/4"
Oven Interior Width
30 5/8"
Oven Interior Depth
16 7/8"
Oven Capacity
4.6 Cu. Ft.
Minimum Circuit Required
15 Amps
Voltage Rating
120 V
Adjustable Leveling Legs
Yes
Included Power Cord Type
3-Prong Plug
LP Conversion Kit Included
Yes
Plinth
Yes
Power Cord Included
Yes
Rear Ventilation Trim
Yes
Backlit Knobs
Yes
Exterior Finish
Smudge-Proof® Stainless Steel
Frigidaire Fit Promise
Yes
Product Weight
240 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
AB-1200
Information available at frigidaire.com/en/ab1200
Bake Element
18000 BTU
Broil Element
1400 Watts
Cleaning System
Yes
Convection
Yes
Convection Element
1400 Watts
Convection Type
Total
Number of Convection Fans
2
Number of Rack Positions
5
Oven Interior Color
Midnight Black
Oven Light Quantity
2
Oven Light Type
Halogen
Oven Light Watts
40 Watts
Rack Position Type
Ladder
Rack Type 1
Flat
Rack Type 1 Quantity
1
Rack Type 2
Glide
Rack Type 2 Quantity
1
Rack Type 3
Air Fry Tray
Rack Type 3 Quantity
1
Display Light Color
White
Display Type
Capacitive Touch
ADA Compliant
Yes
Air FryMake healthier and delicious meals for your entire family - right in your oven.
Slow CookYour food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
Total Convection SystemGives you maximum versatility in the kitchen, powering cooking modes like Air Fry, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Bread Proof, Dehydrate and more!
Six Burner CooktopSix burner cooktop provides the ultimate cooking flexibility, including two powerful 18,000-BTU Quick Boil Burners, two 16,000-BTU burners and a 5,000-BTU simmer.
Temperature ProbeMonitors and alerts when the desired finished cooking temperature has been reached.
Self and Steam Clean CyclesSelect Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
Steam BakeWith Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
Steam RoastSteam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.
Quick PreheatStart cooking in just a few minutes with Quick Preheat
Air Fry Tray is includedAir Fry tray included, perfect for crispy and delicious Air Fry results.
Premium Glide RackOur extending Glide Rack makes it easier to monitor and lift your food out of the oven.
Premium Touch Screen Control PanelFeatures a responsive 4.3 inch, full color, capacitive touch digital control panel.
Backlit LED KnobsLights up when the burner is turned on.
Continuous Cooktop GratesMove even your heaviest pots and pans without the need to lift them.
Convenient Storage CompartmentConvenient drop down door storage compartment is located below the oven cavity, allowing you to store any unused oven racks or baking trays.
Smudge-Proof® Stainless SteelResists fingerprints and cleans easily.
ADA CompliantProduct complies with the Americans with Disabilities Act.
