Air Fry, Audible Signal, Bake, Broil, Cancel/Off, Clock, Control Lock, Cook Time Indicator, Delay Start, Keep Warm/Warm Hold, Sabbath Mode, Start Time, Timer
Power On Indicator Light
Yes
Power Outage Compatible
No
Range Type
Freestanding
Cooktop Details
Cooktop Control Knob Color
Stainless Steel
Cooktop Control Knob Type
Plastic
Cooktop Control Location
Backguard
Cooktop Control Type
Knobs
Cooktop Surface Color
Black
Cooktop Surface Material
Glass
Heating Element On Indicator Light
Yes
Hot Surface Indicator Light
Yes
Certifications
ADA Compliant
No
CUL
Yes
UL
Yes
Electrical
Amps
40
Hz
60
Power Cord Included
No
Volts
120
Other
Capacity (Cu Ft)
5.30
Dimensions & Weight
Width
29.88 in.
Height
47.88 in.
Length
27.75 in.
Weight
160 lbs.
Carton Depth
29
Carton Height
48 3/4
Carton Width
32
Cutout Depth (in)
24
Cutout Height (in)
36
Cutout Width (in)
30
Depth Closed Excluding Handles
25 5/16
Depth Closed Including Handles
28
Depth With Door Open 90 Degree
46.688
Gross Weight
160
Maximum Height
47 7/8
Minimum Height
46 7/8
Net Weight
141.0
Cutout Depth(IN,inches)
24.0000
Cutout Height(IN,inches)
36.0000
Cutout Width(IN,inches)
30.0000
Depth Closed Excluding Handles(IN,inches)
25.3125
Depth Closed Including Handles(IN,inches)
28.0000
Depth With Door Open 90 Degree(IN,inches)
46.6880
Depth(IN,inches)
27.7500
Maximum Height(IN,inches)
47.8750
Minimum Height(IN,inches)
46.8750
Carton Depth(IN,inches)
29.0000
Carton Height(IN,inches)
49.0000
Carton Width(IN,inches)
31.0000
Number of Boxes, Shipping Dimensions, & Shipping Weight
Number of Boxes
1
Shipping Width
34.88 in.
Shipping Height
52.88 in.
Shipping Length
32.75 in.
Shipping Weight
200 lbs.
Total of Shipping Weight
200 lbs.
Source
Calculation
Cubic Feet Measurement & Dimensional Weight
Cubic Feet Measurement
22.97 ft³
Dimensional Weight
285.54 lbs.
Total of Cubes
22.97 ft³
Total of Dimensional Weight
285.54 lbs.
Exterior Details
Door Type
Metal & Glass
Handle Color
Stainless Steel
Handle Material
Metal
Handle Type
Reach Through Handle
Oven Control Knob Color
Stainless Steel
Oven Control Knob Type
Plastic
Oven Control Location
Backguard
Oven Control Type
Electronic Touch
Oven Window Size
Large
Oven Cavity Details
Automatic Convection Conversion Temperature Adjust
No
Bake Element Power
2,400 W
Broiler Element Power
3,400 W
Broiler Location
Top Center
Convection Element Type
None
Convection Functions
No
Door Removable
Yes
Hidden Bake Element
Yes
Interior Color
Black
Number of Oven Lights
1
Number of Oven Racks
2
Number of Rack Guides
5
Oven Cleaning Type
Adjustable Self Cleaning
Oven Cooking System
Convection
Oven Light Switch Location
Top of Console
Oven Light Type
Incandescent
Oven Rack Type
Standard (Both)
Dimensions
Common Size
30 in
Cutout Depth
24 in
Cutout Height
36 in
Cutout Width
30 in
Depth
27-3/4 in
Depth Closed Excluding Handles
25-313/1000 in
Depth Closed Including Handles
28 in
Depth With Door Open 90 Degree
46-86/125 in
Gross Weight
160 lbs
Height
47-7/8 in
Maximum Height
47-7/8 in
Minimum Height
46-7/8 in
Net Weight
141 lbs
Oven Interior Depth
18-1/2 in
Oven Interior Height
18-1/8 in
Oven Interior Width
24-1/2 in
Width
29-7/8 in
Smart Compatibility
Connectivity
No
Works With
No
Element/Burner Details
Center Front Element-Burner Power
100W
Center Front Element-Burner Size
6in.
Center Front Element-Burner Type
Warming
Cooktop Element Style
Radiant
Left Front Element-Burner Power
3,000W
Left Front Element-Burner Size
9in./6in.
Left Front Element-Burner Type
Dual
Left Rear Element-Burner Power
1,200W
Left Rear Element-Burner Size
6in.
Left Rear Element-Burner Type
Standard
Right Front Element-Burner Power
3,000W
Right Front Element-Burner Size
9in./6in.
Right Front Element-Burner Type
Dual
Right Rear Element-Burner Power
1,200W
Right Rear Element-Burner Size
6in.
Right Rear Element-Burner Type
Standard
Refinements
Features
Air Fry
Features
Range Features
Air Fry
Air FryAir Fry allows you to make your favorite fried foods with a crispy-on-the-outside, juicy-on-the-inside taste using little to no additional oil.
5.3 Cu. Ft. CapacityCook the whole meal with plenty of space in this 5.3 cu. ft. capacity electric range.
Proudly assembled in Tulsa, Oklahoma, U.S.A.We take pride in building strong, reliable appliances for your home. These ranges are proudly assembled by hard-working employees in Tulsa, Oklahoma.
An American company for over 100 yearsWhirlpool Corporation started in 1911 in Benton Harbor, Michigan. Today we are a global home appliance business selling products around the world. We are proud of our American heritage and ingenuity that have driven innovation for over 100 years.
10-Year Limited Parts WarrantyWith a 10-year limited parts warranty on the glass cooktop, elements and cavity, we built these ranges tough enough to keep cooking for years.
Dishwasher-safe Air Fry basketJust toss your favorite foods into the 13" x 18" stainless steel basket included in your range for crisp results, and after eating, toss the basket into the dishwasher for easy cleanup.
Fan convection cookingWith two heating elements, fan convection circulates hot air around the oven so you can cook the whole meal at once without having to rotate your dishes for all around baking.
High Temp Self CleanFight the toughest baked-in foods in your oven with this high-heat, self-cleaning technology.
5 ElementsWith an extra element, you have the flexibility to prepare your meal without juggling pots and pans, getting you to dinner fast.
Delay Bake settingWith the Delay Bake setting, just place your dishes in the oven and program when you want the baking to begin so your food is ready when you are.
Hidden Bake ElementThe hidden bake element is sealed under the oven floor to protect it from spills and drips.
Fingerprint resistant stainless finishThe easy-to-clean fingerprint resistant stainless finish keeps your oven looking as good on the outside as it works on the inside.
Warming centerA warming center adds a dedicated cooktop zone to keep your finished food warm while you use the other elements to get the rest of your meal cooked.
9"/6" Dual-Choice™ ElementThe 9"/6" Dual-Choice™ element matches the heat to the pan you’re using so you can cook your meal the way you want.
Ceramic Glass cooktopThe smooth ceramic glass cooktop lets you easily wipe spills from all the delicious meals you‘ll prepare.
Designed to lastThe ceramic glass cooktop and sturdy door hinges on this Maytag® air fry electric range are built for dependability, while fingerprint resistant stainless finish helps make cleaning easier.
